2500A digital clamp meter

UA6050B digital clamp meter with 1000A 1500A 2000A 2500A AC DC current tester

alibaba.com

UA6050B digital clamp meter with 1000A 1500A 2000A 2500A AC DC current tester

1. DC voltage: 400mV/4V/40V/400V/1000V

2. AC voltage: 400mV/4V/40V/400V/750V

3. DC current: 400A/2000A

Basic	Range	Accurate
DC voltage AC voltage	400mV/4V/40V/400V/1000V 400mV/4V/40V/400V/750V	±(0.5%+4) ±(0.8%+10)
DC current AC current	400A/2500A 400A/2500A	±(2.5%+20) ±(2.5%+20)
Consistency	400Ω/4kΩ/40kΩ/400kΩ/4MΩ/60MΩ	±(0.8%+4)
Capacitance	40nF/400nF/4μF/40μF/100μF/400uF/400uF	±(3.5%+8)
Frequency	10Hz/10Mhz	±(0.5%+4)
Diode test		√
On off alarm		√
Low power warning		√
Dusty		√
Data hold		Max value
Function protection		√
Input	10MΩ
Sampling	3/s
Frequency	(50-60)Hz
Operation	manual
Max display	3999
Max jaw	55mm
Power	9V(6F22)
Color	gray
Weight	about 500g (includes battery)
Standard parkage	pencil, battery, manual, warranty card, box
Size	480x320x515mm
Standard packing quantity/gross weight	30pcs/30kg
